QLogic QLE8142 - network adapter - 2 ports

Mfg. Part: QLE8142-SR-CK|CDW Part: 1834026|UNSPSC: 43201558
  • Network adapter
  • PCI Express 2.0 x8 low profile
  • 10 Gigabit LAN
  • 2 ports
Availability:Call
Call for availability
CallCall


This item was discontinued on June 4, 2013.

Sales Assistance

800.808.4239 Mon-Fri 7am-7:30pm CT

Answer within 24 hours.



Untitled Document
Close

Have leasing questions? Let us know how can we help.

Note: Leasing is available to organizations only. Leasing is not available to individuals.
800.808.4239
Mon-Fri 7am-7:30pm CT
Product Overview
Main Features
  • Network adapter
  • PCI Express 2.0 x8 low profile
  • 10 Gigabit LAN
  • 2 ports
The QLE8142 boosts system performance with 10Gbps speed and full hardware offload for FCoE protocol processing. Cutting edge 10Gbps bandwidth eliminates performance bottlenecks in the I/O path with a 10X data rate improvement versus existing 1Gbps Ethernet solutions. Additionally, full hardware offload for FCoE protocol processing reduces system CPU utilization for I/O operations, which leads to faster application performance and higher levels of consolidation in virtualized systems.

The QLE8142 reduces data center costs through convergence. Now, one CNA can do the work of a discrete FC Host Bus Adapter (HBA) and Ethernet NIC. This convergence also means fewer cables, fewer switches, less power consumption, reduced cooling, and easier LAN and SAN management.

The QLE8142 and FCoE are designed to preserve existing investment in Fiber Channel storage and core Ethernet switches and routers for data networking. The QLE8142 leverages the same identical software driver stacks that have been deployed and battle-hardened in millions of previous installations, and preserves familiar FC concepts such as WWNs, FC-IDs, LUN masking, and zoning.
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Dimensions & Weight
Depth: 6.6 in
Height: 2.6 in

Environmental Parameters
Humidity Range Operating: 10 - 90%
Max Operating Temperature: 131 °F
Min Operating Temperature: 32 °F

Header
Compatibility: PC , Unix
Manufacturer: QLOGIC
Model: QLE8142
Packaged Quantity: 1
Product Line: QLogic

Interface Provided
Connector Type: SFP+
Interface: Ethernet 10GBase-SR
Qty: 2
Type: Network

Interface Required
Type: None

Miscellaneous
Compliant Standards: BSMI CNS 13438 Class A , CISPR 22 Class A , EN 60950-1 , EN 61000-3-2 , EN 61000-3-3 , EN55022 Class A , EN55024 , FCC CFR47 Part 15 B , FCC Class A certified , FCC Part 15 B , ICES-003 Class A , IEC 825-1/EN 60825-1 class 1 , MIC , RRL , VCCI Class A ITE
Included Accessories: Full-height bracket , Low-profile bracket
Package Type: Retail

Networking
Compliant Standards: IEEE 802.1p , IEEE 802.1Q , IEEE 802.3ad (LACP) , IEEE 802.3ae , IEEE 802.3ak , IEEE 802.3ap , IEEE 802.3x , UPnP
Connectivity Technology: Wired
Data Link Protocol: 10 Gigabit Ethernet
Data Transfer Rate: 10 Gbps
Features: Data Center Bridging Exchange (DCBX) support , Enhanced transmission selection , Flow control , Full duplex capability , IPv6 support , Jumbo Frames support
Fibre Channel: FC-GS-2 , FC-GS-3 , FC-Tape , FCP-2
Form Factor: Plug-in card
Interface Type: PCI Express 2.0 x8
Low Profile: Low profile
Network Transport Protocol: ARP , iSCSI , TCP/IP , UDP/IP
PCI Specification Revision: PCIe 2.0
Ports Qty: 2
Type: Network adapter

Power Device
Power Consumption Operational: 7.4 Watt
Type: None

Service
Support Details Full Contract Period: 3 years
Support Details Type: Limited warranty

Service & Support
Type: 3 years warranty

Slot Provided
Type: None

Slot Required
Form Factor: Low-profile
Total Qty: 1
Type: PCI Express 2.0 x8

Software
Type: SANsurfer HBA Manager

System Requirements
Min Operating System: Microsoft Windows Server 2003 , Microsoft Windows Server 2008 , Microsoft Windows Server 2008 R2 , OpenSolaris , Red Hat Enterprise Linux Advanced Platform 5 , SunSoft Solaris 10 , VMware ESX Server 3.5 , VMware ESXi 3.5
