All Categories  > Networking Products  > Managed Switches  > SMC EZ Switch 10/100/1000 24-Port Gigabit Web Managed Smart Switch
SMC EZ Switch 10/100/1000 24-Port Gigabit Web Managed Smart Switch View Photo Gallery

SMC EZ Switch 10/100/1000 24-Port Gigabit Web Managed Smart Switch

Mfg. Part: SMCGS24C-SMART  |  CDW Part: 1030729  |  UNSPSC: 43222612

24-port 10/100/1000BASE-T Gigabit Ethernet web managed switch with 4 Combo SFP ports
Main Features
Log On to Email this Page or
Add to Favorites.





Qty
$294.25
Advertised Price
Availability:
Availability
Call for availability.
Call
Product Overview
Technical Specs
Accessories

Compatible Accessories for SMC EZ Switch 10/100/1000 24-Port Gigabit Web Managed Smart Switch

Product Overview Availability Advertised Price
Belkin 8 Outlet, 6' Cord Surge
Surge suppressor - 8 output connector(s)
Availability
In stock and ready for shipment. Ships same day if ordered before 4pm CT.
In Stock
$16.95
Qty
Belkin 14' 650MHz Certified CAT 6 Patch Cable Blue
14' 650MHz Certified CAT 6 Patch Cable RJ-45M/RJ-45M Blue
Availability
In stock and ready for shipment. Ships same day if ordered before 4pm CT.
In Stock
$14.95
Qty
SMC TigerAccess SMC1GSFP-SX TigerAccess SFP Gigabit Transceiver
1-Port 1000BASE-SX (LC) SFP Transceiver
Availability
Orders placed today will ship within 5 days.
3-5 days
$94.75
Qty
Product Overview
Main Features
  • 24-port 10/100/1000BASE-T Gigabit Ethernet web managed switch with 4 Combo SFP ports
SMC Networks' EZ Switch 10/100/1000 (SMCGS24C-Smart) is a 24-port gigabit smart switch with 4 combo ports that bring the speed of gigabit copper to the desktop with the added flexibility of fiber. SMCGS24C-Smart provides a flexible web based management interface to enable the configuration of switch features, port settings including security, QoS with 4 priority queues, link aggregation and VLAN's. These features allow traditionally unmanaged networks to increase throughput and flexibility. Security is becoming critical in next generation networks so this switch has added security features to protect your network. Ideal for users looking to migrate from unmanaged to managed networks, this Smart switch is easy to install and provides 10 times the throughput than 100M switches. The SMCGS24C-Smart switch is a perfect solution for enterprise and SOHO businesses.
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Bay Required
Type: None
Environmental Parameters
Humidity Range Operating: 10 - 90%
Max Operating Temperature: 104 °F
Min Operating Temperature: 32 °F
Header
Compatibility: PC
Manufacturer: SMC Networks
Model: SMCGS24C-Smart
Packaged Quantity: 1
Product Line: SMC EZ Switch
Interface Provided
Connector Type: RJ-45
Interface: Ethernet 10Base-T/100Base-TX/1000Base-T
Qty: 24
Type: Network
Miscellaneous
Compliant Standards: CB , CE , CISPR 22 Class A , EN 60950-1 , EN 61000-3-2 , EN 61000-3-3 , EN 61000-4-11 , EN 61000-4-2 , EN 61000-4-3 , EN 61000-4-4 , EN 61000-4-5 , EN 61000-4-6 , EN 61000-4-8 , FCC Class A certified , IEC 60950-1 , TUV GS , UL 60950-1 , VCCI Class A ITE
Networking
Cabling Type: Ethernet 1000Base-T , Ethernet 100Base-TX , Ethernet 10Base-T
Communication Mode: Full-duplex , Half-duplex
Compliant Standards: IEEE 802.1p , IEEE 802.1Q , IEEE 802.3 , IEEE 802.3u
Connectivity Technology: Wired
Data Link Protocol: Ethernet , Fast Ethernet , Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Empty Slots: 4 x shared SFP (mini-GBIC)
Features: Auto-sensing per device , Auto-uplink (auto MDI/MDI-X) , Flow control , IGMP snooping , Port mirroring , Quality of Service (QoS) , Store and forward , Trunking , VLAN support
Form Factor: External
MAC Address Table Size: 8K entries
Manageable: Yes
Ports Qty: 24
Power Over Ethernet (PoE): No
Remote Management Protocol: HTTP
Status Indicators: Link activity , Port transmission speed , Power
Subcategory (FE): Network hubs and switches
Switching Protocol: Ethernet
Type: Switch
Power Device
Form Factor: Internal
Power Consumption Operational: 28 Watt
Type: Power supply
Service
Support Details Full Contract Period: Lifetime
Support Details Type: Limited warranty
Slot Provided
Free Qty: 4
Total Qty: 4
Type: SFP (mini-GBIC)
Dimensions & Weight
Depth: 6.9 in
Height: 1.7 in, 1.8 in
Weight: 8.2 lbs
Width: 17.3 in, 17.4 in
Service & Support
Type: Limited lifetime warranty
